NEW QUESTION 1
Traditional NAS storage architecture deploys simple two-way failover between two controllers in their storage systems, such as highly-available configurations. How is the Isilon architecture different in terms of system resiliency and availability?

• A. Isilon OneFS enables each node to have a designated partner node for simple failover between the pair.
• B. Isilon solutions can enable failover to other nodes with the use of client-side drivers.
• C. Isilon clustered architecture deploys standby failover nodes to ensure the highest available solution.
• D. Isilon OneFS enables each node to be a peer to any other node in an Isilon cluster.

Answer: D

NEW QUESTION 2
What is the maximum number of data stripes in a Gen 6 Isilon?

• A. 16
• B. 20
• C. 128
• D. 144

Answer: C

NEW QUESTION 3
What is the relative latency of a cache hit to L1 cache compared to a hit to L2 cache in an Isilon cluster?

• A. 2x
• B. 5x
• C. 10x
• D. 25x

Answer: C

NEW QUESTION 4
An Isilon cluster component has the following characteristics:
Spans 3 - 40 nodes
Logical grouping of drives
Automatically assigned
Intelligently distributes disks to manage performance
Which cluster component is described?

• A. Disk pool
• B. Node pool
• C. Smart pool
• D. SSD pool

Answer: A

NEW QUESTION 5
Where does Endurant Cache stage its write cache?

• A. SSD
• B. DISK
• C. NVRAM
• D. DRAM

Answer: B

NEW QUESTION 6
A telecommunications company has a substantial amount of data. This data is being created by network elements within their environment.
The company wants to change the way the network elements Call Detail Records (CDR) are stored and analyzed. The existing infrastructure consolidates all of the CDRs into a table structure, and then ingests them into a large database. Once ingested, a query engine accesses the database and performs analysis on these files. The system is functional; however, since the amount of CDRs generated will increase exponentially over the next year, the company is open to alternatives for storing and analyzing these records.
In evaluating alternatives, the key requirements are to reduce cost, the amount of storage, and the amount of time to analyze the data. The customer would like to use Hadoop to analyze the CDRs.
After you have conducted an assessment of the workflow, you have recommended an Isilon Cluster to work within the Hadoop environment.
Considering the customer's requirements, which is the best node type for the Isilon cluster?

• A. NL400 with 48GB RAM and no SSDs per node
• B. X400 with 96GB of RAM and no SSDs per node
• C. X400 with 24GB RAM and 1.6TB of SSD per node
• D. X200 with 24GB of RAM and 1.2TB of SSD per node

Answer: B

NEW QUESTION 7
A customer needs to consolidate 300 TB of home directory servers and shared file systems used by development and test groups. A key requirement is to prevent the systems from consuming all free capacity and impacting home directory content.
Which Isilon node configuration should be proposed?

• A. X-Series with SmartQuotas
• B. NL-Series with SmartQuotas
• C. S-Series with InsightIQ
• D. X-Series with SmartPools

Answer: A

NEW QUESTION 8
A system administrator has identified a problem on the cluster and has opened a service request on support.emc.com. They initiate isi_gather_info but it is taking a long time to complete.
What can they do to speed up the completion of isi_gather_info for the next run?

• A. Collect the required logs from the syslog server
• B. Restart the CELOG daemon
• C. Increase the speed of the network link
• D. Exclude the specified tool(s) from being gathered

Answer: C

NEW QUESTION 9
Given a 5-node Isilon cluster configured with an N+2 protection level, how many nodes can be offline with the data accessible and fully writeable?

• A. 1
• B. 2
• C. 3
• D. None

Answer: B

NEW QUESTION 10
Your customer is moving from a Restaurant/Bar business model to a Restaurant/Casino business model. You are helping architect the upgrade of a current 4-node X200 48 TB Isilon cluster, with 50% utilized for their video surveillance operations.
They want to upgrade from 15 FPS (NTSC) in H.264 codec, with a 15 days retention policy to 30 FPS (NTSC) in H.264 codec, with a 30 days retention policy.
How many nodes of the same type will you need to add in order to meet the required changes and not exceed 70% raw capacity?

• A. 8 nodes
• B. 4 nodes
• C. 12 nodes
• D. 16 nodes

Answer: A

NEW QUESTION 11
What is the overhead impact on the physical capacity when configuring data protection at +2:1 on a 6-node Isilon cluster?

• A. 1/2
• B. 1/4
• C. 1/5
• D. 1/6

Answer: C

NEW QUESTION 12
A customer has two data centers (Site A and Site B).There is an Isilon cluster in each data center and they use SyncIQ to replicate data between the two data centers.
You have reviewed their disaster recovery plan and found the following:
The policies specify that SyncIQ runs a replication job every 3 hours and that the job finishes within 1 hour.
Three additional hours will be needed to get servers and the network redirected to work from Site B.
What is the Recovery Point Objective in this plan?

• A. 2 Hours
• B. 3 Hours
• C. 4 Hours
• D. 5 Hours

Answer: C

NEW QUESTION 13
You are reviewing an opportunity with a trusted advisor. You both discover gaps in the initial solution design. Each iterative discussion with the customer helps you define the solution better. The documents produced capture the customer's requirements.
What else needs to occur to refine the sizing considerations?

• A. Validate the Workflow Profile Assessment and test the solution against your findings.
• B. Review you assumptions and ask the customer what business issue you're solving.
• C. Provide the CIO with the findings and gain commitment to a Proof of Concept.
• D. Complete your Solution Design Document and forward to EMC consulting.

Answer: A

NEW QUESTION 14
A customer has a 7-node Isilon cluster configured with N+2:1 protection. How many nodes can be offline with the data accessible and fully writeable?

• A. 1
• B. 2
• C. 3
• D. 0; all nodes must be online

Answer: A

NEW QUESTION 15
A customer plans to deploy N+2:1 protection on a 5-node Isilon cluster. How much capacity will be used to store a 320 KiB file?

• A. 320 KiB
• B. 448 KiB
• C. 576 KiB
• D. 640 KiB

Answer: D

NEW QUESTION 16
-- Exhibit -
A European Sports TV network is considering Isilon for their Media Edit Storage for their editing workloads. They are also considering Isilon for near-line media archiving.
The network receives XDCAM HD footage which is loaded onto their existing Transcoding Storage platform. New footage that needs to be edited will be transferred from their Transcoding Storage platform to the proposed Media Edit Storage platform at the rate of ten simultaneous XDCAM HD files via FTP. Edited files will be transferred back to the Transcoding Storage platform at the rate of ten simultaneous XDCAM HD files via FTP.
The network currently has 15 Final Cut Pro edit stations, 15 Avid edit stations. Proxy software will be used to allow Isilon to act as the storage for the Final Cut Pro and Avid media. Three of those edit stations will be performing content compositing as needed.
The network expects 70 hours of new content per week, and 50 hours of edited content per week. They intend to keep the new and edited content on the proposed Media Edit Storage as a performance tier for 30 days. They would like to retain all new and edited footage proposed Media Edit Storage as a near-line tier for two years.
In addition to the current workloads, the network expects to implement a new Media Asset Management (MAM) solution and has requested the Isilon cluster be capable of supporting 120 MBps read and 120 MBps write to support the MAM requirements.
-- Exhibit –

The customer wants to be able to put completed content into a non-editable folder. However, they want to give access to an administrator to delete content if required. What do you recommend to the customer?

• A. SmartLock using Enterprise mode
• B. SmartLock using Compliance mode
• C. WORM using Compliance mode
• D. SyncIQ with read-only mode

Answer: A

NEW QUESTION 17
A customer requires a backup to tape of their Isilon cluster. They want advice on whether to implement a two-way NDMP solution or a three-way solution. The front-end network must be used to stream data to the backup solution. Which cost-effective solution will meet their needs?

• A. Two-way including a Backup Accelerator
• B. Three-way without a Backup Accelerator
• C. Three-way including a Backup Accelerator
• D. Two-way without a Backup Accelerator

Answer: A

NEW QUESTION 18
When designing Isilon solutions, which issue should you pay special attention to?

• A. Meet customer expectations
• B. Create a workflow document
• C. Conduct stakeholder interviews
• D. Follow all SSD sizing rules

Answer: A

NEW QUESTION 19
A customer has a data retention period of three years. They want a solution in which files cannot be deleted, changed, or modified.
Which Isilon SmartLock version should they implement?

• A. Compliance version
• B. Standard version No WORM
• C. Enterprise version
• D. Standard version with WORM

Answer: A

NEW QUESTION 20
An Isilon customer wants to have different snapshot policies and schedules on the same directory. Why is this possible on an Isilon cluster?

• A. SnapshotIQ snaps at the directory level rather than the volume level
• B. All snapshots are scheduled through the command line interface
• C. A third-party product is used by SnapshotIQ to create different schedules and policies on a directory
• D. SnapshotIQ snaps at the volume level rather than the directory level

Answer: A

NEW QUESTION 21
What is the minimum number of connected and available nodes required to maintain quorum in a 25-node Isilon cluster?

• A. 10
• B. 12
• C. 13
• D. 17

Answer: C

NEW QUESTION 22
If a file is 4 KB in size, how much space is consumed for file data when it is written to the Isilon cluster?

• A. 4 KB
• B. 8 KB
• C. 16 KB
• D. 32 KB

Answer: B

NEW QUESTION 23
Your customer is moving from a Restaurant/Bar business model to a Restaurant/Casino business model. You are helping architect the upgrade of a current 4-node X200 48 TB Isilon cluster, with 65% utilized for their video surveillance operations.
They wish to achieve the following:
Upgrade from 1280 x 720 resolution, with a 15 days retention policy, to 2048 x 1536 resolution with a 30 days retention policy.
What is the minimum number of nodes of the same type will you need to add in order to meet the required changes and not exceed 70% raw capacity?

• A. 6 nodes
• B. 10 nodes
• C. 14 nodes
• D. 18 nodes

Answer: A

NEW QUESTION 24
After raw events are processed by the CELOG coalescers, what happens to the data?

• A. Stored in the log databases and coalesced into event groups
• B. Stored in the audit host and coalesced into event groups
• C. Stored in the syslog host and coalesced into event groups
• D. Stored in the log databases and not coalesced into event groups

Answer: B

NEW QUESTION 25
Which Isilon OneFS job, that runs manually, is responsible for examining the entire file system for inconsistencies?

• A. IntegrityScan
• B. MediaScan
• C. AutoBalance
• D. FlexProtect

Answer: A

NEW QUESTION 26
In your second meeting with the customer you ask the following questions about their current unified SAN and NAS platform.
"Are you using an application to map users from NFS Exports to SMB shares? Is each site a separate LDAP or AD Domain?"
What functionality are your trying to understand in their environment and what is the comparable feature in Isilon OneFS?

• A. Identity Mapping and Authentication Sources
• B. User Management and AD Authentication
• C. Kerberos Infrastructure and Identity Management
• D. NFS Export Management and OneFS Cluster Management

Answer: A

NEW QUESTION 27
You are involved with a Proof of Concept where the performance is not what you expect. What can you use to collect process stack information and a listing of process waiting on I/O?

• A. netstat
• B. tcpdump
• C. isi statistics
• D. isi_get_itrace

Answer: C

NEW QUESTION 28
Which type of infrastructure does the Isilon scalable appliance connect to on the front-end?

• A. Ethernet
• B. FICON
• C. Infiniband
• D. Fibre Channel

Answer: A

NEW QUESTION 29
Where are file system changes first stored?

• A. L1 Cache
• B. Endurant Cache
• C. L2 Cache
• D. Journal

Answer: D

NEW QUESTION 30
A customer has two data centers (Site A and Site B). There is an Isilon cluster in each data center and they use SyncIQ to replicate data between the two data centers.
You have been reviewing their disaster recovery plan and found the following:
The policies specify that SyncIQ runs a replication job every 2 hours and that the job finishes within 1 hour.
Three additional hours will be needed to get servers and the network redirected to work from Site
What is the Recovery Point Objective in this plan?

• A. 2 Hours
• B. 3 Hours
• C. 4 Hours
• D. 5 hours

Answer: B

NEW QUESTION 31
......
