NEW QUESTION 1
What is used to resolve IP address to MAC address mappings?

• A. DHCP
• B. ARP
• C. DNS
• D. ICMP

Answer: B

Explanation:
https://enWikipedia.org/wiki/Address_Resolution_Protocol

NEW QUESTION 2
in which scenario is a full proxy required?

• A. When a separation between client and server connection .s needed
• B. When administration directly access the servers for administration
• C. when the server sends the response through Iho load balancer
• D. when all TCP client parameters must be seen by the server

Answer: A

Explanation:
Reference https //devcentral.f5.com/articles/three-things-your-proxy-cart-do-unless-its-a-full-proxy

NEW QUESTION 3
The 2001:db8: : IP6 address block is allocated to a load balancer for use as virtual server addresses. The address block is routed to a balancer self IP address using a static route. What is the correct representation for the last address in the address block that a virtual server can use?

• A. 2001:db8
• B. 2001:db8: : 255
• C. 2001:db8: : ffff:ffff:ffff:fffe
• D. 2001:db8: :ffff:ffff:ffff:ffff

Answer: C

NEW QUESTION 4
A BIO IP Administrator is troubleshooting a slow web application. A packet capture shows that some of the packets coming from a window size of zero A packet capture shows that som a window size of zero
What does this mean?

• A. The client is trying to close the TCP connection
• B. The server is trying to close the TCP connection
• C. The server is temporary unable to receive any more data
• D. The client is temporarily unable to receive any more data

Answer: C

NEW QUESTION 5
An administrator points the browser at h.tp://www mydomain com.The destination server listens on TCP port 8080 Which feature must be enabled on the virtual server for this configuration to work?

• A. HTTP persistence
• B. source NAT
• C. destination address affinity
• D. port translation

Answer: D

Explanation:
https.//support f5.com/csp/article/K93G17176

NEW QUESTION 6
The HTTP 1.1 standard is being used as part of communication to a server. The client fails to maintain the session within the maximum timeout defined by the server. Which device is responsible for ending the HTTP session?

• A. the load balancer
• B. the server
• C. the default gateway of the load balancer
• D. the client

Answer: C

NEW QUESTION 7
In a load balanced scenario which service would require persistence to function correctly?

• A. Simple Mail Transport Protocol
• B. DNS
• C. Web-based email
• D. HTTP

Answer: C

NEW QUESTION 8
An administrate receives an error message when attempting to create a self-IP address on a BIG-IP appliance Which address should the administrator use to resolve the issue?

• A. 2001 0db8.85a3 0000 0000 8a2e 0370 7334
• B. 2001:db8:85a3 Bd3.Ba2e.370 7334
• C. 2001:0db8:85i3:0000:0000: : 8a2i:0370:7334

Answer: A

NEW QUESTION 9
What is the primary function of a certificate authority?

• A. to expire outdated certificates
• B. to verify and validate certificates
• C. to store security certificates
• D. to sign certificate signing requests

Answer: D

Explanation:
https:/enWikipedia.org/wiki/Certificale_authority

NEW QUESTION 10
What should the BIG-IP Administrator configure to perform SSL offloading when the certificate is already imported on the BIG-IP device?

• A. HTTP profile using client SSL profile
• B. Virtual server using client SSL profile configured to use the certificate
• C. Virtual server using server SSL profile configured to use the certificate
• D. HTTP profile using server SSL profile

Answer: B

NEW QUESTION 11
A BIG-IP Administrator needs a solution to tunnel traffic and transmit encrypted connections over the Internet using only a standard browser and common ports and protocols. Which solution should the administrator select?

• A. GRE Tunnel
• B. iPsec VPN
• C. SSH Tunnel
• D. SSL VPN

Answer: D

Explanation:
This is APMs use of the netscape plugin api (NPAPI) that most browsers have deprecated at this point.

NEW QUESTION 12
If there are multiple applications authenticated against a single identity store, which technology solution will simplify access to all applications?

• A. RADIUS
• B. single sign on
• C. multifactor authentication
• D. LDAP

Answer: B

NEW QUESTION 13
An administrator deploys a site in which the load balancer only sees the ingress traffic from the client All
egress traffic from the server bypasses the load balancer. Which type of solution is this?

• A. packet forwarding architecture
• B. delayed binding
• C. switching
• D. Full proxy architecture

Answer: A

NEW QUESTION 14
An administrator configures secure remote access to a server's shell Given the netstal output, what did the administrator configure?

• A. teinet
• B. allowing connections only from IP address 10 .1. 10.46
• C. ssh
• D. listening on IP address 10. 1. 10.46
• E. ssh
• F. allowing connections only from IP address 10.1. 10. 46
• G. teinetd listening on IP address 10.1. 10. 46

Answer: B

Explanation:
Although it appears telnet is configured in this example (!) it is listening on all IP addresses of the system while ssh (port 22) is only on the 10.1.10.46 address.

NEW QUESTION 15
Client A from the 192. 162. 168.0. 0 0/24 network wants to send a Ping to Client B on 10.10.10..0/24.
The Default Gateway from Client A IS 192.168.0. 1
The MAC Address of Client A is00 11. 11. 11. 11
The MAC Address of client B is 00.22 22.22.22
The MAC Address of Default Gateway is 00. 33.33. 33. 33
What is the destination MAC Address of the ping packet when it leaves client A interface card?

• A. 00. 11. 11. 11. 11
• B. f1. f1. f1. f1. f1
• C. 00.33. 33. 33. 33
• D. 00. 22. 22. 22. 22

Answer: C

NEW QUESTION 16
An administrator needs to rapidly deter e newly discovered security threat to a remote desktop application. Which F5 feature provides this functionality?

• A. iRules
• B. SSL profiles
• C. Proxy SSL
• D. SPDY

Answer: A
