NEW QUESTION 1
During a maintenance window, an EUD test was executed and the output displayed on the screen. The BIG-IP Administrator did NOT save the screen output. The BIG-IP device is currently handling business critical traffic. The BIG-IP Administrator needs to minimize impact. What should the BIG-IP Administrator do to provide the EUD results to F5 Support?

• A. Boot the device into EUD then collect output from console
• B. Execute EUD from tmsh and collect output from console
• C. Collect file /var/log/messages
• D. Collect file /shared/log/eud.log

Answer: D

NEW QUESTION 2
You have a pool of servers that need to be tested. All of the servers but one should be tested every 10 seconds, but one is slower and should only be tested every 20 seconds. How do you proceed?

• A. It cannot be don
• B. All monitors test every five seconds.
• C. It can be done, but will require assigning monitors to each pool member.
• D. It cannot be don
• E. All of the members of a pool must be tested at the same frequency.
• F. It can be done by assigning one monitor to the pool and a different monitor to the slower pool member.

Answer: D

NEW QUESTION 3
The 8IG-IP Administrator generates a qkview using "qkview -SO" and needs to transfer the output file via SCP.
Which directory contains the output file?

• A. /var/log
• B. /var/tmp
• C. /var/local
• D. /var/config

Answer: B

NEW QUESTION 4
Refer to the exhibit


The network team creates a new VLAN on the switches. The BIG-IP Administrator needs to create a configuration on the BIG-IP device. The BIG-IP Administrator creates a new VLAN and Self IP, but the servers on the new VLAN are NOT reachable from the BIG-IP device.
Which action should the BIG-IP Administrators to resolve this issue?

• A. Set Port Lockdown of Set IP to Allow All
• B. Change Auto Last Hop to enabled
• C. Assign a physical interface to the new VLAN
• D. Create a Floating Set IP Address

Answer: C

NEW QUESTION 5
Under what condition must an appliance license be reactivated?

• A. Licenses only have to be reactivated for RMAs no other situations.
• B. Licenses generally have to be reactivated during system software upgrades.
• C. Licenses only have to be reactivated when new features are added (IPv6, Routing Modules, etc) no other situations.
• D. Neve
• E. Licenses are permanent for the platform regardless the version of software installed.

Answer: B

NEW QUESTION 6
A BIG-IP Administrator uses backend servers to host multiple services per server. There are multiple virtual servers and pools defined, referencing the same backend servers.
Which load balancing algorithm is most appropriate to have an equal number of connections on each backend server?

• A. Least Connections (member)
• B. Least Connections (node)
• C. Predictive (member)
• D. Predictive (node)

Answer: B

Explanation:
The same set of servers provides multiple services, that is, using different ports to provide different services at the same time. The stem requirement is based on server connection balancing, not server + port, so it is node.

NEW QUESTION 7
A 8IG-IP Administrator configures a Virtual Server to load balance traffic between 50 webservers for an
ecommerce website Traffic is being load balanced using the Least Connections (node) method.
The webserver administrators report that customers are losing the contents from their shopping carts and are unable to complete their orders.
What should the BIG-IP Administrator do to resolve the issue?

• A. Change Default Persistence Profile setting to cookie
• B. Change Load Balancing method to Ratio (member)
• C. Change Default Persistence Profile setting to sipjnfo
• D. Change Load Balancing method to Ratio (node)

Answer: A

NEW QUESTION 8
A BIG-IP Administrator needs to apply a health monitor for a pool of database servers named DB_Pool that uses TCP port 1521.
Where should the BIG-IP Administrator apply this monitor?

• A. Local Traffic > Profiles » Protocol > TCP
• B. Local Traffic > Nodes > Default Monitor
• C. Local Traffic > Pools > De Pool > Members
• D. Local Traffic > Pools > DB Pool > Properties

Answer: D

NEW QUESTION 9
Assume a virtual server has a ServerSSL profile. What SSL certificates are required on the pool members?

• A. No SSL certificates are required on the pool members.
• B. The pool members.SSL certificates must only exist.
• C. The pool members.SSL certificates must be issued from a certificate authority.
• D. The pool members.SSL certificates must be created within the company hosting the BIGIPs.

Answer: B

NEW QUESTION 10
A virtual server is listening at 10.10.1.100:any and has the following iRule associated with it: when CLIENT_ACCEPTED { if {[TCP::local_port] equals 21 } { pool
ftppool } elseif {[TCP::local_port] equals 23 } { pool telnetpool }
If a user connects to 10.10.1.100 and port 22, which pool will receive the request?

• A. ftppool
• B. telnetpool
• C. Non
• D. The request will be dropped.
• E. Unknow
• F. The pool cannot be determined from the information provided.

Answer: D

NEW QUESTION 11
A local user account (Users) on the BIG-IP device is assigned the User Manager role. Userl attempts to modify the properties of another account (User2), but the action fails. The BIG-IP Administrator can
successfully modify the User2 account.
Assuming the principle of least privilege, what is the correct way to allow User 1 to modify User2 properties?

• A. Move User2 to the same partition as User1
• B. Grant User1 administrative privileges
• C. Move User to the same partition as User2.
• D. Modify the partition access for User 1

Answer: D

NEW QUESTION 12
A 8IG-IP Administrator is making adjustments to an iRule and needs to identify which of the 235 virtual
server configured on the BIG-IP device will be affected.
How should the administrator obtain this information in an effective way?

• A. Local Traffic > Virtual Server
• B. Local traffio Pools
• C. LOCAL Traffic > Network Map
• D. Local traffic > Rules

Answer: C

NEW QUESTION 13
A BIG-IP has a virtual server at 150.150.10.10:80 with SNAT automap configured. This BIG-IP also has a SNAT at 150.150.10.11 set for a source address range of 200.200.1.0 / 255.255.255.0. All other settings are at their default states. If a client with the IP address 200.200.1.1 sends a request to the virtual server, what is the source IP address when the associated packet is sent to the pool member?

• A. 200.200.1.1
• B. 150.150.10.11
• C. Floating self IP address on VLAN where the packet leaves the system
• D. Floating self IP address on VLAN where the packet arrives on the system

Answer: C

NEW QUESTION 14
Refer to the exhibit.

An LTM device has a virtual server mapped to www.f5.com. Users report that when they connect to
/resources/201.1.2h.l_l.com they are unable to receive content. What is the likely cause of the issue?

• A. The pool associated with the virtual server does not have priority group activation enabled.
• B. The virtual address does not have ARP enabled.
• C. The virtual address does not have route advertising enabled.
• D. The pool associated with the virtual server is falling its health check.

Answer: B

NEW QUESTION 15
A BIG-IP Administrator needs to find which modules have been licensed for use on the BIG-IP system. In which section of the Configuration Utility can the BIG-IP Administrator find this information?

• A. System > Services
• B. System > Resource Provisioning
• C. System > Platform
• D. System > Support

Answer: B

NEW QUESTION 16
Assume a virtual server has a ServerSSL profile. What SSL certificates are required on the BIG-IP?

• A. No SSL certificates are required on the BIG-IP.
• B. The BIG-IP's SSL certificates must only exist.
• C. The BIG-IP's SSL certificates must be issued from a certificate authority.
• D. The BIG-IP's SSL certificates must be created within the company hosting the BIG-IPs.

Answer: A

NEW QUESTION 17
A Standard Virtual Server for a web application is configured with Automap for the Source Address Translation option. The original source address of the client must be known by the backend servers. What should the BIG-IP Administrator configure to meet this requirement?

• A. The Virtual Server type as Performance (HTTP)
• B. An HTTP profile to insert the X-Forward-For header
• C. An HTTP Transparent profile
• D. A SNAT Pool with the client IP

Answer: B

Explanation:
Because it is a web application, you can insert the source IP in the xff field in the http profile.
