NEW QUESTION 1
Which Virtual Server type should be used to load balance HTTP traffic to a pool of servers?

• A. Standard
• B. Stateless
• C. Forwarding (IP)
• D. Forwarding (Layer 2)

Answer: A

NEW QUESTION 2
A BIG-IP Administrator wants to add a new Self IP to the BIG-IP device. Which item should be assigned to the new Self IP being configured?

• A. Interface
• B. Route
• C. VLAN
• D. Trunk

Answer: C

NEW QUESTION 3
When configuring a pool member's monitor, which three association options are available? (Choose three.)

• A. inherit the pool's monitor
• B. inherit the node's monitor
• C. configure a default monitor
• D. assign a monitor to the specific member
• E. do not assign any monitor to the specific member

Answer: ADE

NEW QUESTION 4
New Syslog servers have been deployed in an organization. The BIG-IP Administrator must reconfigure the BIG-IP system to send log messages to these servers.
In which location in the Configuration Utility can the BIG-IP Administrator make the needed configuration changes to accomplish this?

• A. System > Logs > Configuration
• B. System > Configuration > Local Traffic
• C. System > Logs > Audit
• D. System > Configuration > Device

Answer: A

NEW QUESTION 5
A virtual server is defined per the charts. The last five client connections were to members C, D, A, B, B. Given the conditions shown in the above graphic, if a client with IP address 205.12.45.52 opens a connection to the virtual server, which member will be used for the connection.

• A. 172.16.20.1:80
• B. 172.16.20.2:80
• C. 172.16.20.3:80
• D. 172.16.20.4:80
• E. 172.16.20.5:80

Answer: D

NEW QUESTION 6
A BIG-IP Administrator must determine if a Virtual Address is configured to fail over to the standby member of a device group in which area of the Configuration Utility can this be confirmed?

• A. Device Management > Traffic Groups
• B. Device Management > Devices
• C. Local Traffic > Virtual Servers
• D. Device Management > Overview

Answer: C

NEW QUESTION 7
In the BIG-IP Configuration Utility, a user requests a single screen view to determine the status of all Virtual Servers and associated pool members, as well as any iRules in use. Where should the BIG-IP Administrator instruct the user to find this view?

• A. Local Traffic > Monitors
• B. Local Traffic > Virtual Servers
• C. Local Traffic > Network Map
• D. Statistics

Answer: C

Explanation:
Network Map can display vs and its associated pool, pool member, and irule, can be retrieved, and can be quickly linked.

NEW QUESTION 8
A virtual server at 10.10.1.100:80 has the rule listed below applied.
when HTTP_REQUEST { if {[HTTP::uri] ends_with "htm" } { pool pool1 } else if {[HTTP::uri] ends_with "xt" } { pool pool2 }
If a user connects to http://10.10.1.100/foo.txt which pool will receive the request?

• A. pool1
• B. pool2
• C. Non
• D. The request will be dropped.
• E. Unknow
• F. The pool cannot be determined from the information provided.

Answer: B

NEW QUESTION 9
A BIG-IP Administrator uses a device group to share the workload and needs to perform service on a BIG-IP device currently active for a traffic group. The administrator needs to enable the traffic group to run on another BIG-IP device in the device group. What should the administrator do to meet the requirement?

• A. Create a new Traffic Group and then fail to Standby Unit
• B. Select Traffic Group and then select Failover
• C. Select Traffic Group and then select Force to Standby
• D. Select Traffic Group on Primary Unit and then select Demote

Answer: C

NEW QUESTION 10
Refer to the exhibit
The BIG-IP Administrator is unable to access the management console via Self-IP 10.10 1.33 and port 443. What is the reason for this problem?

• A. Packet Filter needs to be configured to allow a source
• B. Self IP is configured to allow TCP All
• C. Self IP is configured to allow UDP 443
• D. Packet Filter is configured to allow port 443

Answer: C

NEW QUESTION 11
Refer to the exhibit.
A user notifies the BIG-IP Administrator that http://remote company.com is NOT accessible. Remote access to company resources must be encrypted.
What should the BIG-IP Administrator do to fix the issue?

• A. Change the Listening Port on remote.company.com_vs to Port 80
• B. Add a Pool to the Virtual Server remote.company.com_VS
• C. Add an iRule to remote.company.com_vs to redirect Traffic to HTTPS
• D. Change the Type of the Virtual Server remote.company.com_vs to Forwarding

Answer: C

Explanation:
Requiring all traffic to be HTTPS access requires HTTP requests to be redirected directly to HTTPS.

NEW QUESTION 12
Refer to the exhibit. The BIG-IP Administrator needs to avoid overloading any of the Pool Members with connections, when they become active.
What should the BIG-IP Administrator configure to meet this requirement?

• A. Different Ratio for each member
• B. Same Priority Group to each member
• C. Action On Service Down to Reselect
• D. Slow Ramp Time to the Pool

Answer: D

NEW QUESTION 13
Refer to the exhibit.

A BIG-IP Administrator configures a Virtual Server to handle HTTPS traffic. Users report that the application is NOT working.
Which actional configuration is regard to resolve this issue?

• A. Configure SSL Profile (Client)
• B. Configure Protocol Profile (Server)
• C. Configure Service Profile HTTP
• D. Configure SSL Profile (Server)

Answer: A

NEW QUESTION 14
Which method is recommended for creating a new user from the CLI?

• A. Run f5adduser username' then 'f5passwd username' from bash or tmsh
• B. Run tmsh create auth user username prompt for password' from bash
• C. edit bigip.conf to add the new user and the user's clear-text password
• D. Run useradd username' then 'passwd username' from bash tmsh

Answer: B

NEW QUESTION 15
The BIG-IP appliance fails to boot. The BIG-IP Administrator needs to run the End User Diagnostics (EUD) utility to collect data to send to F5 Support.
Where can the BIG-IP Administrator access this utility?

• A. Console Port
• B. Internal VLAN interface
• C. External VLAN interface
• D. Management Port

Answer: A

NEW QUESTION 16
Which three methods can be used for initial access to a BIG-IP system? (Choose three.)

• A. CLI access to the serial console port
• B. SSH access to the management port
• C. SSH access to any of the switch ports
• D. HTTP access to the management port
• E. HTTP access to any of the switch ports
• F. HTTPS access to the management port
• G. HTTPS access to any of the switch ports

Answer: ABF

NEW QUESTION 17
The incoming client IP address is 195.64.45.52 and the last five connections have been sent to members A, C, E, D and B. Given the virtual server, pool, and persistence definitions and statistics shown in the above graphic, which member will be used for the next connection?

• A. 10.10.20.1:80
• B. 10.10.20.2:80
• C. 10.10.20.3:80
• D. 10.10.20.4:80
• E. 10.10.20.5:80
• F. It cannot be determined with the information given.

Answer: C
