NEW QUESTION 1
Which Cisco video endpoints run on the Android operating system?

• A. EX-Series
• B. DX-Series
• C. C-Series
• D. MXP-Series

Answer: B

NEW QUESTION 2
When a user attempts to sign in with a Jabber Video for Cisco TelePresence client, which SIP message is the first that is sent?

• A. INFO
• B. NOTIFY
• C. REGISTER
• D. SUBSCRIBE

Answer: D

NEW QUESTION 3
When connecting to a pan-tilt-zoom camera to a C-Series codec, what type of cable must be used for camera control?

• A. an Ethernet crossover cable (RJ45-to-RJ45)
• B. an Ethernet cable (RJ45-to-RJ45)
• C. a serial cable (DB25-to-DB9)
• D. a VISCA cable (DB9-to-RJ45)

Answer: D

NEW QUESTION 4
Which two Cisco TelePresence protocols are supported for content sharing in point-to-point and multipoint meetings? (Choose two.)

• A. BFCP
• B. ICE
• C. Switched Presentation
• D. Auto Collaboration
• E. H.323

Answer: AD

Explanation: https://www.cisco.com/c/en/us/td/docs/telepresence/interop/1_8/deployment/guide/Interop_Release1_8/present.

NEW QUESTION 5
A new Cisco DX650 is not registering in the Cisco Communications Manager running version 9.1.2. The latest device package and firmware was uploaded on all Cisco Communications Manager servers in the cluster. What is most likely the cause of this issue?

• A. A cluster-wide reboot is needed to enable the functionality.
• B. You must restart the TFTP server.
• C. The firmware in the Cisco Unified Communications Manager is incorrect.
• D. The software version in the Cisco Unified Communications Manager is incorrect.

Answer: A

Explanation: Topic 4, Conferencing Concepts

NEW QUESTION 6
A company wants to enable a mobile user to connect to the corporate network to access calls, messages, video conferencing, and web collaboration. Which product provides these features for the user?

• A. Cisco WebEx Connect
• B. Cisco Unified Presence
• C. Cisco TelePresence SX20
• D. Cisco Jabber

Answer: D

NEW QUESTION 7
Which standard will support call forwarding?

• A. H.450.3
• B. H.323
• C. RFC 2833
• D. H.450.2

Answer: A

NEW QUESTION 8
Which bridge solution requires Cisco TelePresence Conductor?

• A. Cisco TelePresence Server operating in remotely managed mode
• B. Cisco TelePresence Server operating in locally managed mode
• C. Cisco TelePresence MCU operating in remotely managed mode
• D. Cisco TelePresence MCU operating in locally managed mode

Answer: A

NEW QUESTION 9
An engineer is configuring Cisco TCS to record video conferences. The customer’s requirement is to configure 30 recording aliases and to enable automatic creation of future aliases. Which two configurations are required for this solution? (Choose two.)

• A. SIP registration between Cisco TCS and Cisco VCS
• B. configuring recording alias settings to copy on Cisco TCS
• C. custom system call configuration on Cisco TCS
• D. SIP registration between Cisco TCS and Cisco TelePresence MCU
• E. H.323 registration between Cisco TCS and Cisco VCS

Answer: CE

NEW QUESTION 10

Refer to the exhibit. An SX80 endpoint has been deployed using dual screens and a third display is being added. To which connector must the third display be connected?

• A. A
• B. B
• C. C
• D. D
• E. E
• F. F

Answer: C

NEW QUESTION 11
An engineer is configuring the brightness on a Cisco SX10 endpoint with default configuration via the CLI with the xConfiguration Cameras Camera 1 Brightness Level: 1 command but notices no changes to the local display brightness level. Which option is the reason for this issue?

• A. The codec must be rebooted for the changes to take effect.
• B. The display brightness was changed from the remote end.
• C. The default brightness level is 1.
• D. The brightness mode must be set to manual.

Answer: A

NEW QUESTION 12
Which DHCP option is used by video endpoints to locate the Cisco Communications Manager TFTP server to download the endpoints configuration?

• A. option 43
• B. option 82
• C. option 150
• D. option 176
• E. option 242

Answer: C

NEW QUESTION 13
Which two methods can be used to set the default call protocol of a Cisco TelePresence endpoint running TelePresence codec firmware? (Choose two.)

• A. Use the GUI and set System > H.323 > Settings > Default Call Protocol > H.323.
• B. Use the CLI command xConfiguration Conference 1 DefaultCall Protocol: H323.
• C. Use the CLI command Conference Default Protocol: H323.
• D. Use the CLI command Default Protocol: H323.
• E. Use the GUI and set Configuration > System Configuration > Conference > DefaultCall > H.323.

Answer: BE

NEW QUESTION 14
Conference solution for video streaming: (Choose two)

• A. TCS
• B. VCS
• C. TMS
• D. TS
• E. MCU 4500

Answer: AE

NEW QUESTION 15
Which three features are supported by Cisco TMSPE? (Choose three.)

• A. Simplified provisioning
• B. LDAP user import
• C. Scheduling via Microsoft Outlook
• D. FindMe
• E. Jabber for Windows
• F. Automatic endpoint upgrades

Answer: ABD

NEW QUESTION 16
ACisco TelePresence VCS displays this alarm: "Root password is set to default." How can this security warning be addressed?

• A. Use the Cisco TelePresence VCS web user interface, choose Administration > User Settings, and change the root password.
• B. Use SSH to log in to the Cisco TelePresence VCS as Administrator and issue the command xconfig root set passwd.
• C. Use SSH to log in to the Cisco TelePresence VCS as Root, issue the command set password, and enter the new password when prompted.
• D. Use SSH to log in to the Cisco TelePresence VCS as Root, issue the command passwd, and enter the new password when prompted.
• E. Use the Cisco TelePresence VCS web user interface, choose Administration > System Settings, and change the root password.

Answer: D

NEW QUESTION 17
Which two of these are required in order to complete the password recovery of a Cisco TelePresence System endpoint? (Choose two.)

• A. must have FTP enabled on the endpoint
• B. must have SSH enabled on the endpoint
• C. must have the security question answer for the endpoint
• D. must be in the same room as the main display
• E. must have SFTP enabled on the endpoint
• F. must call Cisco TAC for the security code

Answer: BD

NEW QUESTION 18
Which two additional items must be configured for an endpoint to register manually with the Cisco TelePresence Video Communication Server for the SIP to function correctly? (Choose two.)

• A. E.164 alias
• B. H.323 ID
• C. SIP uniform resource indicator
• D. configured SIP registrar and proxy server
• E. NTP server IPv4 address
• F. unique system ID

Answer: CD
