NEW QUESTION 1
In the web interface for a Cisco VCS or Expressway running X8.2, which page allows you to enable and download logs that include the xConfiguration, xStatus, DEBUG level network logs, and packet captures of both network interfaces?

• A. Maintenance > Diagnostics > Diagnostic Logging
• B. Maintenance > Diagnostics > System Snapshot
• C. Status > Logs > Event Log
• D. Status > Logs > Configuration Log

Answer: A

NEW QUESTION 2
You want to output SIP messaging to the console of a Cisco TelePresence endpoint running Cisco TelePresence Conductor software. Which two commands can you enter into the CLI together to accomplish this goal? (Choose two.)

• A. log ctx SipPacket debug 9
• B. log output on
• C. log ctx output
• D. log SipPacket debug 9
• E. log output console

Answer: AB

NEW QUESTION 3
Which command causes a Cisco VCS to drop registrations for currently registered endpoints only if they are not currently in a call?

• A. xConfiguration SystemUnit Maintenance Mode: Off
• B. xConfiguration SystemUnit Maintenance Mode: On
• C. xConfiguration Zones LocalZone DefaultSubZone Registrations: "Deny"
• D. xConfiguration Registration RestrictionPolicy Mode: "DenyList"

Answer: B

NEW QUESTION 4
Jabber fail login with logs. What DNS SRV record need to resolve this issue?

• A. _SIP
• B. _SIPS
• C. _EDGE
• D. _cisco-uds

Answer: D

NEW QUESTION 5
Which three standards are supported for streaming live video on Cisco TCS? (Choose three.)

• A. H.265
• B. H.261
• C. H.264
• D. H.263
• E. H.262
• F. H.270

Answer: BCD

NEW QUESTION 6
A customer requires scheduled Cisco TelePresence video conferencing and the capability for ad hoc conferencing. Which product would be recommended for the customer?

• A. Cisco TMS and an MCU with port capacity that can fulfill both needs
• B. Cisco TMS with an MCU and Cisco Unified CM with an MCU
• C. Cisco TMS with two MCUs
• D. Cisco Unified CM with two MCUs
• E. Cisco Conductor with an MCU
• F. Cisco Conductor integrated with Cisco TMS and an MCU

Answer: B

NEW QUESTION 7
An engineer is selecting a digital media player and must ensure that there are Ethernet downlink ports. Which model has these ports?

• A. 4310 DMP
• B. Edge 340 DMP
• C. Edge 300 DMP
• D. 4400 DMP

Answer: C

NEW QUESTION 8
Which three Cisco TelePresence multipoint media conferencing platforms can utilize Cisco Unified Communications Manager for call control? (Choose three.)

• A. Cisco TelePresence Multipoint Control Unit
• B. Cisco TelePresence System 500-32
• C. Cisco TelePresence Server
• D. Cisco TelePresence Media Bridge Server
• E. Cisco TelePresence Multipoint Switch
• F. Cisco TelePresence SX20

Answer: ACE

NEW QUESTION 9
Which four features are supported by Cisco TelePresence Server for all hardware models in remotely managed mode? (Choose four.)

• A. auto-attendant
• B. ClearPath
• C. Cluster sizes of more than 5 servers
• D. Cascading
• E. Active presence for all devices
• F. Support for Conductor
• G. Native scheduling capabilities

Answer: BDEF

NEW QUESTION 10
Which two methods can be used to retrieve the status of a Cisco TelePresence codec endpoint? (Choose two.)

• A. From the codec web GUI, choose Troubleshooting > System Status.
• B. From the codec web GUI, choose Diagnostics > System Status.
• C. From the codec web GUI, choose Configuration > System Status.
• D. Run the xstatus command from the CLI.
• E. Run the xcommand status command from the CLI.

Answer: CD

NEW QUESTION 11
You have been informed from the field that a new Cisco TelePresence video endpoint has been deployed with an IPv4 address of 172.28.254.45. You need to check for connectivity from the Cisco Unified Communications Manager server. Which command should be entered to check for network connectivity?

• A. utils network traceroute newsystem.domain254.local
• B. utils network ping 172.28.254.45
• C. ping 172.28.254.45
• D. traceroute 172.28.255.255
• E. utils network host cucm.osl147.local

Answer: B

NEW QUESTION 12
An end user is in Cisco TelePresence session with a remote participant and can control the camera at the remote endpoint. Which feature is underlying in this scenario?

• A. FEC
• B. DTMF
• C. FECC
• D. PIP

Answer: C

NEW QUESTION 13
What is the main difference between a Cisco TelePresence Multipoint Control Unit and a Cisco TelePresence Multipoint Switch?

• A. The Cisco TelePresence Multipoint Control Unit is a hardware bridg
• B. The Cisco TelePresence Multipoint Switch is a software bridge.
• C. The Cisco TelePresence Multipoint Control Unit is a software bridge for immersive and non-immersive endpoint
• D. The Cisco TelePresence Multipoint Switch is a hardware bridge for non-immersive endpoints.
• E. The Cisco TelePresence Multipoint Control Unit delivers automatic voice-activated switchin
• F. The Cisco TelePresence Multipoint Switch provides active presence.
• G. The Cisco TelePresence Multipoint Control Unit has a latency of less than 10 ms, whereas the Cisco TelePresence Multipoint Switch has a latency of 100 ms.

Answer: A

NEW QUESTION 14





The Cisco Telepresence Codec C90 is unable to call the Cisco IP Video Phone. Assuming that the calling
search space has been configured correctly, which of the these can cause this issue?

• A. The Cisco Telepresence Codec C90 can only be registered to a Cisco Telepresence Video Communication Server.
• B. A multipoint control unit is required in order for the call to work.
• C. The Cisco Telepresence Codec C90 can only be registered as a SIP endpoint to Cisco Unified Communications Manage
• D. H.323 is not supported.
• E. URI dialing has not been configured on Cisco Unified Communications Manager.
• F. The Cisco Telepresence Codec C90 Profile 1 > CallSetupMode must be configured as a gateway since Cisco Unified Communications Manager does not have a gatekeeper functionality.
• G. The Cisco Telepresence Codec C90 is not registered as a SIP endpoint on Cisco Unified Communications Manage
• H. The Cisco Telepresence Codec C90 needs to be registered as both SIP and H.323.

Answer: C

NEW QUESTION 15
A customer owns three Codian 5300 MCUs with several video endpoints. Users complain that they are getting multipoint control unit port capacity errors when scheduling video conferences in Cisco TMS. What can be done to correct these errors automatically?

• A. Enable the Automatic MCU Cascading option in the Cisco TMS Conference Settings.
• B. Install a Cascading option key on the Cisco TMS server.
• C. Install a Cisco TelePresence Conductor server.
• D. Install cascaded multipoint control units.

Answer: C

NEW QUESTION 16
Which of these needs to be enabled in Cisco Unified Communications Manager in order for the Cisco TelePresence System 500-32 to be able to share a presentation with a Cisco TelePresence System Codec C40 endpoint that is registered to a VCS?

• A. Allow iX application media
• B. Send send-receive SDP in mid-call invite
• C. Allow presentation sharing using BFCP
• D. Allow presentation sharing using H.235
• E. Deliver conference bridge identifier

Answer: C

NEW QUESTION 17
An engineer is using a cascading feature with Cisco TelePresence Conductor and Cisco TelePresence Servers. Which two limitations will the engineer likely encounter? (Choose two.)

• A. Ad-hoc conferencing cascading is not supported.
• B. Only single-screen endpoints are supported through cascading links.
• C. Multiple-screen endpoints are supported only with three or more Cisco TelePresence Servers.
• D. Scheduled conferencing is not supported.
• E. Ad-hoc conferencing cascading is supported only with three or more Cisco TelePresence Servers.

Answer: AD

NEW QUESTION 18
When configuring the Cisco TelePresence System 500 with a static IP address, where should the IP address be configured?

• A. in Cisco Unified Communications Manager after adding the Cisco TelePresence System 500 manually
• B. in the Cisco TelePresence System Administration tool
• C. in the Cisco TelePresence Management Suite after the Cisco TelePresence System 500 was added under systems
• D. Static IP address configuration is not possibl
• E. Only a DHCP-provided IP address is supported.
• F. using the on-screen display

Answer: B
